Turbine Controls and Associated Devices
2301E-ST Steam Turbine Controls
LOW COST – Steuerung auf Basis von 2300E – Hardware
8273-1013
2301E-ST – Steam Turbine Control
8273-1014
2301E-ST – Steam Turbine Control, Hazardous Location Zone 2
*
Documentation Product Spec: 03407, Manual: 26694
Hydro Turbine Controls
LOW COST – Steuerung auf Basis von 2300E – Hardware
8237-2046
2301E-HT – Hydro Turbine Control (Francis), 24 VDC, Ordinary Location
*
Documentation Product Spec: 03459, Manual: 35092
Steuerung auf Basis von 505 – Hardware
8200-1400
505HT – LVDC, Pelton Turbines
8200-1401
505HT – HVAC/DC, Pelton Turbines
*
Documentation: Product Spec: 03460, Manual: 35116
8200-1402
505HT – LVDC, Francis / Kaplan Turbines
8200-1403
505HT – HVAC/DC, Francis / Kaplan Turbines
Zubehör:
8269-1073
17” TouchPanel OCP – Includes RemoteView Software Program
8928-5311
RemoteView – Software License
Peak200 Steam Turbine Controls
LOW COST – Dampfturbinensteuerung mit Turbinen mir einem HP-Valve
8200-1500
Peak200 – Bulkhead Mount, Low Voltage
8200-1501
Peak200 – Bulkhead Mount, High Voltage
8200-1502
Peak200 – Bulkhead Mount, LV, ATEX Zone 2
8200-1503
Peak200 – Front Panel Mount, LV
8200-1504
Peak200 – Front Panel Mount, HV
8200-1505
Peak200 – Front Panel Mount, LV, ATEX Zone 2
8200-1508
Peak200 – Bulkhead Mount, HV, Class1 Div2 Haz. Loc. Compliant
8200-1509
Peak200 – Front Panel Mount, HV, Class1 Div2 Haz. Loc. Compliant
*
Documentation Product Spec: 03438, Manual: 35051
505 Steam Turbine Controls
Dampfturbinensteuerung mit oder ohne Display
8200-1300
505 – LVDC, Ordinary Location
8200-1301
505 – HVAC/DC, Ordinary Location
8200-2302
505 – LVDC, ATEX, Zone 2 Hazardous
*
Documentation: Product Spec: 03422, Manuals: 26839V1, 26839V2
8200-1310
505-XT – LVDC, Ordinary Location
8200-1311
505-XT – HVAC/DC, Ordinary Location
8200-2312
505-XT – LVDC, Zone-2 Hazardous Location
*
Documentation: Product Spec: 03423, Manuals: 35018V1, 35018V2
8200-1330
505-DR – LVDC, Ordinary Location
8200-1331
505-DR – HVAC/DC, Ordinary Location
5541-705
Flex500DR FTM Kit – DR FTM, Interconnection Cables
*
Documentation: Product Spec: 03423, Manuals: 35018V1, 35018V2, 35018V3
Zubehör:
8200-1203
LinkNet-HT Analog 4-20 mA Module (8 AI and 2 AO)
8200-1200
LinkNet-HT RTD Module (8 RTD Inputs)
8200-1204
LinkNet-HT Discrete Input Module (16 DIs)
8200-1205
LinkNet-HT Discrete Output Module (16 DOs)
8928-5311
RemoteView Software License
Wird fortgesetzt …..
